| Model and specification | JB23-16 | JB23-25 | JB23-40 | JB23-60 | JB23-80 |
|---|---|---|---|---|---|
| Nominal pressure (kn) | 160 | 250 | 400 | 630 | 800 |
| Slipper stoke (mm) | 50 | 70 | 80 | 80 | 100 |
| Slipper stoke times(time/min) | 110 | 65 | 50 | 50 | 50 |
| Max closing height (mm) | 170 | 200 | 220 | 250 | 270 |
| Height adjustment(mm ) | 30 | 30 | 45 | 5 | 60 |
| Distance between slipper centre and machine(mm) | 160 | 200 | 200 | 250 | 260 |
| Worktable dimension(mm) | 320*460 | 350*520 | 390*630 | 420*650 | 470*750 |
| Size of die handle bore (mm) | 40*60 | 40*60 | 50*70 | 50*70 | 60*80 |
| Worktable thickness(mm) | 45 | 50 | 70 | 70 | 80 |
| Slipper underside bore (mm) | 120*180 | 170*220 | 210*250 | 240*280 | 260*300 |
| Motor(kw) | 1.5 | 3 | 4 | 5.5 | 5.5 |
| Dimension(mm) | 1130*830*1890 | 1120*860*2200 | 1600*1100*2250 | 1740*1100*2650 | 1765*1265*2650 |
